Rebar Coupler
Build Stronger, Build Smarter! Mechanical splicing solutions for seamless reinforcement bar connections.
Rebar Coupler
Atlantis Engineering specializes in mechanical splicing solutions for the construction industry, delivering high-quality rebar couplers backed by years of expertise. From design to manufacturing, testing, logistics, and rebar threading, we provide end-to-end solutions.
Enhanced Strength
Superior load transfer vs. lap splicing
Zero Welding
No hot work or fire hazards on site
Faster Construction
Quick installation saves project time
Atlantis Structural Coupling Systems
Atlantis Rebar Couplers are engineered to connect reinforcement bars seamlessly, offering a superior alternative to lap joints—efficient, cost-effective, and high-performance.
- IS 16172 Compliant for unmatched reliability
- Ideal for Piles, Pile Caps, Walls, Slabs, Beams, Columns & Precast Connections
- Powering infrastructure, residential & commercial projects with innovation
Build Greener, Build Lighter! With Atlantis Splicing System, create sustainable, high-strength structures while reducing material wastage and construction costs.
Lap Splicing
Overlapping rebars tied together — higher steel consumption, congestion, and longer installation time.
Atlantis Mechanical Splicing
End-to-end coupler connection — less steel waste, no welding, faster construction, IS 16172 compliant.
Benefits
Why choose Atlantis mechanical splicing over traditional lap joints
Save Cost
Lesser steel consumption compared to lap splicing — reduce material waste and project cost.
Save Time
Faster construction cycles with quick coupler installation on site.
No Torque Wrench
Simple hand installation — no special tools required for connection.
Solves Congestion
Eliminates overlapping lap lengths and reduces rebar congestion in tight zones.
Better Concrete Flow
Improved concrete flow and consolidation around splice locations.
IS 16172 Compliant
Fully compliant couplers manufactured and tested to Indian standards.
Cost Saving Opportunity — 50D
| Dia of Bar (mm) | No. of Lap | Lap Length (50D) | Lap Length Bar (mm) | Weight per Meter (kg) | Total Weight (kg) | Rate (₹) | Amount (₹) |
|---|---|---|---|---|---|---|---|
| 16 | 1 | 0.8 | 800 | 1.58 | 1.264 | 60 | 75.84 |
| 20 | 1 | 1.0 | 1000 | 2.469 | 2.469 | 60 | 148.14 |
| 25 | 1 | 1.25 | 1250 | 3.858 | 4.823 | 60 | 289.38 |
| 32 | 1 | 1.6 | 1600 | 6.321 | 10.114 | 60 | 606.84 |
Coupler Types & Products
Parallel Threaded Couplers
Atlantis parallel threaded couplers connect reinforcement bars from Ø 16 mm to 40 mm. Rebar threads are parallel threaded by a roller threading machine.
Features
- Cost effective alternative to lap splicing
- Load transfer independent of concrete grade
- Quick and efficient operation
Applications
- Residential Apartments
- Commercial Buildings
- Non-Slender Structures
Cold Forged Couplers
Atlantis cold forged couplers have proven splicing performance under compression, tension, cyclic and fatigue loads. Designed to withstand ultimate tensile performance up to 650 MPa. Rebar ends are enlarged by cold forging and threaded on-site. Recommended for seismic conditions. Available in sizes 16 mm to 40 mm.
- Save cost by reducing rebar consumption
- Positive alignment and locking
- Class L and Class H couplers available
Parallel Thread Couplers
Roller-threaded parallel connections for Ø 16–40 mm bars.
Cold Forged Couplers
Enlarged and threaded ends for seismic and high-load applications.
Reducer Couplers
Connect rebars of different diameters in a single splice.
MBT Couplers
Mechanical bolt-type couplers for specialized connections.
Technical Specifications
RECOMMENDED
| TMT Bar Dia (mm) | Outer Dia (mm) | Length (mm) | Weight | Threading Pitch |
|---|---|---|---|---|
| 16 | 28 | 40 | 125 | M18×2/2.5 |
| 20 | 34 | 54 | 225 | M23×2.5 |
| 25 | 45 | 64 | 505 | M29×3.00 |
| 32 | 53 | 80 | 830 | M35×3.00 |
| 40 | 63 | 100 | 1400 | M43×3.00 |
| TMT Bar Dia (mm) | Outer Dia (mm) | Length (mm) | Weight | Threading Pitch |
|---|---|---|---|---|
| 16 | 25 | 36 | 72 | M18×2/2.5 |
| 20 | 32 | 50 | 164 | M23×2.5 |
| 25 | 40 | 60 | 321 | M29×3.00 |
| 32 | 50 | 64 | 540 | M32×3.00 |
| 40 | 60 | 70 | 1025 | M43×3.00 |
RECOMMENDED
| TMT Bar Dia (mm) | Outer Dia (mm) | Length (mm) | Weight | Threading Pitch |
|---|---|---|---|---|
| 16 | 25 | 40 | 82 | M18×2/2.5 |
| 20 | 32 | 54 | 184 | M23×2.5 |
| 25 | 42 | 64 | 403 | M29×3.00 |
| 32 | 50 | 78 | 670 | M35×3.00 |
| 40 | 63 | 96 | 1310 | M43×3.00 |
| TMT Bar Dia (mm) | Outer Dia (mm) | Length (mm) | Weight | Threading Pitch |
|---|---|---|---|---|
| 16 | 25 | 40 | 90 | M17×2/2.5 |
| 20 | 32 | 50 | 195 | M21×2.5 |
| 25 | 40 | 60 | 355 | M26×3.00 |
| 32 | 50 | 80 | 725 | M33×3.00 |
| 40 | 63 | 90 | 1239 | M41×4.00 |
Services & Coupler Types
On-Site Services
Expert Threading & Mobilization
At Atlantis, our skilled workforce delivers top-quality on-site threading services with advanced technology and a customer-first approach — ensuring efficiency, safety, and quality on every project.
Cold Forging & Threading
Precision rebar end preparation on site
Mobile Threading Van
Plug-and-play model for congested sites
Machine Mobilization
Flat PCC base, rebar stand and shed setup
Type A
Standard Coupler
Length of rebar threading corresponds to half length of coupler. Ideal for straightforward end-to-end splicing in standard applications.
Type B
Position Coupler
Thread on the rebar is extended to full coupler length. No rotation of bars is required for connection — perfect for fixed or congested layouts.
Clientele
65+
Projects
40+
Clients
35+
Team Size
2.5M
Sq.ft. Project Area
Quality Assurance
Tested & Traceable
Each coupler passes through Go/No-Go gauges. We use CNC machines for manufacturing and strictly follow IS 16172-2014.
EN8D Material Test
Tensile Test
Pull Out Test
Slip Test
Chemical Composition
Go / No-Go Gauge
Each coupler carries a Unique Identification Number (UIN) for end-to-end traceability from raw material to delivery.
Quality · Speed · Efficiency · Cost
Unique Identification Numbers (UIN) are marked on each coupler ensuring end-to-end traceability from raw material to delivery. Every coupler is tested with Go & No-Go plug gauges. Box packaging ensures products reach you in good condition.
We use only standard company materials to ensure the highest quality in our rebar couplers — guaranteeing strength, durability, and reliability for every construction project.
